ENGLISH

DESCRIPTION OF OPERATION

2
USB
2
This USB input is suited for the connection with a PC/laptop computer to manage the functions of the
MUSWAY DSP software to set-up the DSP functions of the device. The connection is USB 1.1/2.0/3.0
compatible. For downloading the software please visit "www.musway.de/dsp".
BT
3
This USB input is suited for an external Bluetooth
or adjusting the DSP by an APP through a smart phone/mobile device.
Check the website "www.musway.de" for more information or ask your car audio retailer.
DRC
4
This input is suited for an external MUSWAY digital remote controller. Check the website "www.mus-
way.de" for more information or ask your car audio retailer.
OPT IN
5
This devices accepts through its Optical input PCM stereo signals up to 96 kHz / 24 bit sampling fre-
quency rate. Multi-channel signals coming from audio/video sources (such as the audio tracks of a film
in DVD) can not be reproduced. Connect a fiber optic cable with a TOSLINK connector.
HIGH LEVEL INPUT
6
Connect here the amplified speaker outputs coming from the head unit by using the enclosed 12 pole
multipolar connector.
CAUTION: Do NOT use the High Level Input and the Line Input at the same time.
POW ON SEL
7
The device can be turned on/off by using the following methods:
SPK: Slide the switch into position SPK, if you want to turn on/off the device through
the CH1 input channel of the high level speaker inputs and its Auto Turn-On function.
REM: Slide the switch into position REM, if you want to turn on/off the device through the REM IN
and a turn-on signal from head unit/car stereo in low level operation.
8
3
5
4 6
dongle with wireless audio streaming function with/
®
7
