Montageanleitung / mounting instruction
ECOLED II Smartbox
ANSCHLÜSSE DIN RH /
2 1 2
1 GND 1 GND
Tail
2 Tail 2
(SMCG)
max. 3A
max. 5A
SMCG
CONNECTORS DIN RH
4
5
1
6
1 2 3
GND Tail Reverse
3
1
2
7
4 5 6 7
DI Stop Fog -
-
2 1
2
1 GND 1 GND
2 Tail 2 Reverse
max. 5A max. 5A
1
12
