Anschlüsse Ass2 Lh - Aspöck Systems ECOLED II Smartbox Montageanleitung

Montageanleitung / mounting instruction
ECOLED II Smartbox
ANSCHLÜSSE ASS2 LH /
Adapter benützen!
Use adapter!
2 1
2
1 GND 1 GND
2 Reverse 2 Tail
max. 5A max. 5A
CONNECTORS ASS2 LH
6
5
1
7
1/4 2 3
DI LH Fog GND
3
1/4
8
2
5 6 7 8
- Stop Tail LH Reverse
-
2
1
2
1 GND 1 GND
Tail
2 2 Tail
(SMCG)
max. 3A
max. 5A
SMCG
1
11
