ZyXEL Powerline PLA6456 Schnellstartanleitung

PLA6456
G.hn Wave 2 Powerline Pass-thru Gigabit
Ethernet Adapter
Quick Start Guide
ENGLISH | DEUTSCH | ESPAÑOL | FRANÇAIS
ITALIANO
1 1 1 Hardware Installation
Not Recommended
ON
1 st PLA6456
Device for
Internet access
LAN
2 nd PLA6456
LAN
EN
For better performance, it is recommended not to plug a PLA
into a power extension cord.
Connect one PLA to a device for Internet access, such as a
router. Connect the other PLA to a device requiring Internet over
Powerline.
DE Für eine bessere Leistung wird empfohlen, einen PLA nicht mit
einem Verlängerungskabel zu verbinden.
Verbinden Sie unseren PowerLine Adapter (PLA) mit einem
Gerät für den Internetzugang und einen anderen mit einem
Gerät, das Internet über Powerline bezieht.
ES Para un mejor rendimiento, se recomienda no enchufar un PLA
en un cable alargador.
Conecte un PLA a un dispositivo para acceso a Internet y otro a
un dispositivo que necesite Internet por línea eléctrica.
FR
Pour de meilleures performances, il est recommandé de ne pas
brancher un PLA dans une rallonge électrique.
Connecter une PLA à un appareil pour l'accès internet et une
autre pour un appareil passant par une ligne électrique pour
internet.
IT Per ottenere un rendimento migliore si consiglia di non collegare
un'unità PLA con un cavo di prolunga.
Connettere uno dei PLA al router con accesso ad Internet, e
l'altro al dispositivo che necessita di accesso a Internet tramite
Powerline.
1 1 2 Check LED Lights
Green On - Power is on.
Blinking - Encrypt in processing.
Power
Off - Power off.
Green On - More than 80 Mbps - Best.
Amber On - 20 to 80 Mbps - Good.
Red On - 0 to 20 Mbps - see Troubleshooting.
Powerline
Off - Internet is not ready.
Green On - The Ethernet connection is up.
Ethernet
Optional More Secure
Room1
1 PLA6456
st
within
2
minutes
ENCRYPT
Hold for 2 seconds
Room2
EN
The Powerline light indicates how good your Powerline
connection is.
More Secure (Optional)
The PLAs must have an active Ethernet connection to use the
ENCRYPT button.
DE Das Powerline-Licht zeigt an, wie gut die Powerline-Verbindung
ist.
Mehr Sicherheit (optional)
Der PowerLine Adapter (PLA) benötigt eine Ethernet-Verbind-
ung, um den VERSCHLÜSSELUNGS-Knopf nutzen zu können.
ES La luz Powerline indica la calidad de la conexión de su línea
eléctrica.
Más seguro (opcional)
Los PLAs debe tener una conexión Ethernet para usar el botón
ENCRYPT.
FR
La lumière Powerline indique la qualité de votre connexion
électrique.
Plus de Sécurité (option)
Les PLAs doivent avoir une connexion Ethernet pour pouvoir
utiliser le bouton ENCRYPT.
IT
Il led Powerline indica la qualità della connessione tramite
Powerline.
Più sicuro (Opzionale)
I PLA devono avere una connessione Ethernet per poter usare il
pulsante ENCRYPT.
Troubleshooting
• If the power light does not come on, make sure the PLA is turned on.
If an Ethernet light does not come on, please check the Ethernet
•
cable.
If the Powerline light does not turn on, this means there is no
•
communications between PLA devices. This can be due to other PLA
devices not being plugged in to electrical outlets yet, PLA device is
possibly in low power mode or there is an issue on the power circuit.
Make sure that the PLAs are on the same power circuit. Test by
connecting PLAs into nearby outlets. Make sure that you do not
have a power meter between them.
To minimize interference, move PLAs away from high powered
•
electrical devices such as refrigerators, air-conditioners, microwave
ovens, etc.
• When securing the Powerline network, make sure not to press the
ENCRYPT/Reset buttons on both PLAs for more than 5 seconds. If
the process fails, press the said button on both PLAs over 10
seconds to reset to factory setting, then try to reconnect again.
See the User's Guide for more troubleshooting tips.
•
2 PLA6456
nd
ENCRYPT
Hold for 2 seconds
Support Information
North America
USA
+ 1 800 255 4101
support@zyxel.com
UK
+ 44 (0) 118 9121 700
support@zyxel.co.uk
Germany
+ 49 (0) 2405 69 09 0
support@zyxel.de
See the User's Guide at www.zyxel.com for more information,
including customer support and safety warnings.
