Installation
Choosing a Place for Installing the Monitor
Take into account the need for cables when choosing a place to install the device. It is recommended that the device be
placed at eye level of the user.
Installation of Mounting Frame under Video Monitor
Place the frame on the mounting spot, mark out the locations for mounting holes and drill them into the wall. Sufficient
space must remain in the centre of the frame for cables to the monitor (cable from the camera, power supply cable). Attach
the frame using screws.
Connecting the Cables
Connect the door camera units to the monitor by plugging the cables into the labelled terminals on the monitor.
Hanging the Monitor
Gently press the monitor to the frame so that the protrusions lock into the opening at the rear of the monitor. Pushing the
monitor slightly downwards will fix it in place.
Connecting the Device to the Power Grid
Connect the power supply to a grid which meets the 230 V/50 Hz parameters of the device.
Plug the power supply connector (output) into the prescribed socket at the rear of the video monitor.
Installation of the Door Camera Unit
see Fig. 3
Choose a suitable place for mounting and attach the mounting hood.
Pull the power supply cable through the mounting opening and connect it to the terminal at the rear of the door camera unit.
Attach the connected door camera unit to the hood using the enclosed screws.
Door Camera Unit on Plaster
Apply a layer of silicone between the wall and the door camera unit to prevent ingress of humidity under the door camera
unit. The silicone should be applied on the top and the sides. The bottom side must be left open to allow humid air from
exiting the space under the door camera unit.
Parameters of Interlinking Cables
We recommend using a high-quality RVV/CYSY cable for communication:
Distance <50 m: 2× 0.5 mm
2
Distance >50 m: 2× 1 mm
2
To control the door lock – 12 V DC out: RVV/CYSY cable: 2× 1.0 mm
To control the gate – zero voltage contact: RVV/CYSY cable: 2× 1.0 mm
Basic Operation of the Device
To ring the bell and call up the image from the door cam-
era unit on the videophone, press the button on the door
camera unit. Audio from outside will also be transmitted
to the monitor.
To accept a call, press this button on the monitor:
Maintenance of the Device
The device is low-maintenance. It is recommended, based on the condition of the device, to occasionally wipe the device
down with a moistened cloth.
Attention!
Before cleaning, the device must be disconnected from power!
FAQ
The device does not work
Check the cables and the connection of the power supply to the grid.
If you used an extension cable on the power supply cord, check that the polarity is correct. Measure the power supply with
a multimeter. The output voltage on the connector should be 15 V DC (+/- 1 V).
2
2
To immediately call up the image from the door camera
unit and CCTV camera, press this button:
Press the UNLOCK button to unlock the corresponding
door or to open the gate
