Worx Landroid L1000 Installation Seite 9

You can place the charging station on your lawn or on a hard surface like a walkway, provided that the lawn and the hard surface are at
the same height (no steps).
To enter the station, Landroid needs at least 80cm straight path in front. On the exit side, it needs at least 30cm straight path before a left
turn (fig. 1). If the turn is to the right, there is no need for a straight path (fig. 2).
1
30cm
3
3. Charging station checklist:
A . within reach of AC mains
B. in shade
C. straight path on entrance; straight path on exit if necessary
D. flat land
E. no irrigation sprinklers nearby
4. Placement of boundary wire on slopes
The upper boundary wire should NOT be placed on slopes steeper than 35% (20°)*. The lower boundary wire should NOT be
placed on slopes steeper than 17% (10°), and it should be placed at least 40cm away from any obstacle when positioned on a
slope that is 17%.
26cm
17%~35%
8
2
80cm
4
<17%
*How to calculate the slope of your lawn:
The slope would be:
35 cm (Elevation)
100 cm (Length)
40cm
35cm
Max. 35% slope
EN
80cm
0 °
= 35% (slope)
100cm
Length
