Hacker Motor GmbH
Schinderstraßl 32
Tel.: 0049 (0) 871-953628-0
Fax.:0049 (0) 871-953628-29
info@hacker-motor.com
D-84030 Ergolding
Manual for the PROGBOX
Welcome to the team!
Thank you for choosing the HACKER PROGBOX. With the PROGBOX you can calibrate the
parameters of the TENSORIC controller series and the regulator - and also update the
firmware.
The PROGBOX work stand alone, or as an interface for connecting a PC via the USB cable.
CONECTION OF CONTROLER AND PROGBOX
1.
Connect the controller with the battery.
2.
Connect the controller via the sensor cable with the adapter cable.
3.
Plug the adapter cable into the PROGBOX.
4.
Switch on your controller.
1.
Connect the controller with the battery.
2.
Plug the receiver cable into the PROGBOX.
3.
Switch on your controller.
1.
Connect the controller with the battery
2.
Disconnect the vent on the controller.
3.
Plug the adapter cable into the PROGBOX.
4.
Connect the controller by plug in the adapter cable into the vent. socket.
5.
Switch on your controller.
HOW TO USE THE PROGBOX
1.
After switching on the controller the PROGBOX indicates the software version
of the PROGBOX.
2.
Push any button on the PROGBOX
3.
The PROGBOX connects with the controller indicating „CONNETING ESC".
4.
The software version of the controller is indicated.
ADJUSTING OF THE CONTROLLER
1.
Using the „ITEM"-button you can select the parameter you want to change.
2.
Der Wert eines Parameters kann mit der „VALUE"-Taste verändert werden.
3.
Nach der Auswahl des richtigen Wertes, müssen Sie diesen mit der „SAVE"-
Taste speichern.
4.
Mit der „RESET"-Taste gelangen Sie immer wieder an den Anfang.
5.
Schalten Sie den Regler nach der Programmierung aus.
PC-SOFTWARE
The PROGBOX used in conjunction with a PC and the available software works as an
INTERFACE.
In conjunction with the PC software, you can update the software on the controller and the
PROGBOX.
Using the software, you can change the same parameters as with the PROGBOX.
The software can be found in the DOWNLOAD AREA at: www.hacker-motor.com.
TECHNICAL INFORMATION
Voltage: 4.5 bis 6.0 VDC
Diamension: 90x51x17mm
Weight : 84g
GERNERAL WARRANTY PROVISIONS
Hacker Motor GmbH products will be manufactured in accordance with the highest quality
criteria's.
We provide the legal guarantee, to be free of defects on material and workmanship.
There will be no liability for typical use sign of wear.
The warranty does not cover defects which are a result of misuse, improper maintenance, or
mechanical damage.
This is among other things on:
Not followed the instructions
o
o
Mechanical damage
o
Disassembly or modification.
Before returning your product for repair, please check all other components in order to avoid
any operator error.
DECLARATION OF CONFORMITY
For the products manufactured by Hacker Motor GmbH mentioned in this manual the compel-
ling and relevant EC Directive will apply:
EMV-Directive: 2004/108/EG
The following special directives will apply:
EN 61000-6-1:2007
EN 61000-6-3:2007
Ergolding, 04.02.2012
Information for Users on disposal of electrical equipment and electronic
equipment (private households)
According to the basic business principles, your product is made from
high quality materials, which are recyclable and reusable.
This symbol on the products and / or accompanying documents means that used electrical and
electronic products must be at the end of their lifetime separated from household waste.
Please take these products for the treatment, recovery and recycling to designated collection
points, which will receive the devices free of charge.
The Proper disposal of this product, prevent any potential adverse effects on humans and the
environment which could otherwise arise from inappropriate waste handling at the end of its
lifetime. For more precise details of your nearest designated collection point, contact your local
authority.
For business users in the European Union
Please contact your dealer or supplier for further information if you wish to dispose electrical
and electronic equipment. He holds further information ready for you.
Information on Disposal in other Countries outside the European Union.
This symbol is only valid in the European Union.
Hacker Motor GmbH
Schinderstraßl 32
D-84030 Ergolding
Tel: +49 871-953628-0
Fax: +49 871-953628-29
E-Mail: info@hacker-motor.com
Copyright ©, Hacker Motor GmbH 2012
Irrtum und Änderungen vorbehalten
WEEE-Reg.-Nr. DE 55352581
Copyright 2012 Hacker Motor GmbH. All rights reserved.
