You can also uninstall the software from "add or Remove programs" in the control panel.
click "add or Remove": the choose setup language screen will display. click "oK. " When
the confirm File Deletion prompt displays, click "oK" to confirm, then click "Finish. "

Operation

any connected usB device will link to the computers connected to port 1 and port 2 of
the switch. the computer connected to port 1 will be the active link until the usB device is
redirected to another connected computer.
1
COMPUTER
A
2
COMPUTER
A
3
COMPUTER
A
to control usB auto-sharing without any "device busy"
indications, press ctrl/F11 to display the "Enforce switching"
prompt, then click "Yes" to confirm any switching of ports.
NOTE: Even without the usB sharing application installed
(Mac, linux), switching access to the connected usB device from one computer to
another can be done manually by pressing the select button on the top of the switch
that corresponds to the desired port. if the select button/lED is lit, the corresponding
computer is already linked to the usB device. (only one lED will light at any given time.) a
flashing lED indicates that the corresponding port is processing a redirect command and
is not yet ready for activity. (Refer to the Read Me file on the cD for details.)
COMPUTER
Green
COMPUTER
Green
COMPUTER
Yellow
B
Yellow
B
Red
B
Green
Computer A is connected to —
and is ready to use — the
USB device.
To make Computer B ready to
use the USB device, right-click
the on-screen indicator icon or
press Ctrl/F11.
Computer A is currently using
the USB device.
While the USB device is being
used by Computer A, switching
to another computer (such as
Computer B) is not allowed.
To make Computer A ready to
use the USB device, right-click
the on-screen indicator icon or
press Ctrl/F11.
Computer B is connected to —
and is ready to use — the
USB device.
