Installation
a) Choosing a Location
• The camera recording angle and sensor detection is affected by the placement of the device.
• Consider placing where the solar panels have maximum exposure to sunlight.
• Check that the device is within range of your Wi-Fi access point. Use of other 2.4 GHz products e.g.
wireless networks and microwave ovens may cause interference.
• You may need to set up a wireless repeater to improve the connection.
b) Mounting
Check that the provided screws are appropriate for the surface material. If in doubt consult a
professional.
Consider the camera and motion detection angles when choosing a location. Test this before
drilling holes and mounting.
1. Use the holes on the mounting plate as a template to mark where to drill.
2. If needed, insert the plastic dowels using a mallet.
3. Fix the mount to the wall using the supplied screws.
4. Screw the device onto the mount, making sure the rubber gasket forms a good seal around the mount-
ing points.
5. Make sure the device is securely attached to the mounting bracket before letting go.

Operation

A) Power ON
• Press and hold the power button to turn the camera ON.
B) Pairing mode
• If the camera is not paired with the app:
- You will hear a voice prompt that the camera is ready to pair.
- The LED status indicator will flash blue.
• If the camera is already paired with the app:
- The LED status indicator will be solid blue
- The camera will function as usual.
C) Reset the camera
Perform a reset if the camera is not functioning correctly or you would like to enter pairing mode.
1. Insert the included reset pin into the reset hole.
2. Press down until you feel a "click" then hold 4-5 seconds.
3. Stop pressing when you hear the voice prompt "system reset ...".
D) Power OFF
• If you continue to press and hold reset after the prompt has sounded, the device will power off.
Low light recording
If the camera is placed behind glass, glare from infrared LED lights may overexpose the image.
The device is equipped with a light sensor that automatically triggers "night vision" when ambient
light falls below a certain level.
The recorded image will be in black and white.
Motion detection
• With a microSD card inserted:
- 15 second clips will be saved until the SD card is full.
- You will receive notifications on your phone
• If no microSD is inserted, or if the SD card is full:
- No clips will be saved.
- You will receive notifications on your phone, then open the app to view live video (with option to save
to mobile device memory).
Application connection tips
The device will not connect to your Wi-Fi network if the password contains any of the
following characters (" \ ). Please remove those characters from your password if needed.
• This device is only compatible with 2.4 GHz networks.
• Have the password for your Wi-Fi router ready.
• Connect the mobile phone or tablet to same Wi-Fi network the camera will connect to.
Pairing: "Add device" → "Video Surveillance" → "Smart Camera"
Care and cleaning
Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as they
can cause damage to the housing and malfunctioning.
• Clean the product with a fibre-free cloth, slightly dampen if needed.
• Do not apply excessive force to the solar panels during the cleaning process.
Declaration of Conformity (DOC)
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this product con-
forms to the 2014/53/EU directive.
Click on the following link to read the full text of the EU declaration of conformity:
www.conrad.com/downloads
Select a language by clicking on a flag symbol and enter the product order number in the search
box. You can then download the EU declaration of conformity in PDF format.
Disposal
a) Product
Electronic devices are recyclable waste and must not be disposed of in the household waste.
At the end of its service life, dispose of the product in accordance with applicable regulatory
guidelines.
Remove any inserted (rechargeable) batteries and dispose of them separately from the product.
b) (Rechargeable) batteries
You as the end user are required by law (Battery Ordinance) to return all used (rechargeable)
batteries. Disposing of them in the household waste is prohibited.
Contaminated (rechargeable) batteries are labeled with this symbol to indicate that disposal
in the domestic waste is forbidden. The designations for the heavy metals involved are: Cd =
Cadmium, Hg = Mercury, Pb = Lead (name on (rechargeable) batteries, e.g. below the trash icon
on the left).
Used (rechargeable) batteries can be returned to collection points in your municipality, our stores or wherever
(rechargeable) batteries are sold.
You thus fulfill your statutory obligations and contribute to the protection of the environment.
Technical data
a) General
Input voltage / current ........................... 5 V/DC, 2 A
Rechargeable batteries ........................ Li-Ion, 3.7 V 2600 mAh (type 18650)
1 to 4 pcs
Operating current .................................. 250 mA (day mode)
450 mA (night mode)
Charging time ....................................... 6 - 8 hrs (USB), 27 h (solar panel)
Standby power consumption ................ 130 µA
Audio .................................................... 2-way (microphone and speaker)
Resolution ............................................. HD 1920 x 1080 p, SD 640 x 360 p
Frames per second ............................... 15 fps
Recording ............................................. Continuous loop (motion activated)
File record size in ................................. 15 s (in motion detection mode)
Until SD card full (manual recording)
Video format ......................................... *.media
Focal length .......................................... 3.6 mm
Field of view .......................................... 90°
Storage ................................................. MicroSD (max 32 GB)
MicroSD file system .............................. FAT32
Ingress protection ................................. IP66
Power cable type .................................. USB A to MicroUSB
Operating / storage conditions .............. -10 to +50 °C, 0 – 90 % RH (non-condensing)
Dimensions (W x H x D) ....................... 96 x 69 x 203 mm (camera)
Weight .................................................. 580 g (camera)
b) Motion detection
IR LED .................................................. max. 15 m range
<10 lux trigger LED
Motion detection ................................... PIR (Passive Infrared)
PIR detection angle .............................. 110°
Detection range .................................... 8 m
c) Wireless connectivity
Bandwidth ............................................. Min. 2 Mbps upload speed
WLAN technology ................................. IEEE 802.11 b/g/n, 2.4 GHz
Frequency ............................................. 2.412 - 2.472 GHz
Transmission power.............................. < 23 dBm
Transmission distance .......................... max. 50 m (line of sight)
d) Solar Panel
Output voltage / current ........................ 5.5 V/DC, max. 240 mA
Output power ........................................ max. 1.32 W
e) Application software
Supported OS ....................................... Android 4.2 (or higher),
iOS 9.0 (or higher)
