Technical Data - Silvercrest SGWZ 1 A1 Kurzanleitung

1 LED Status
2 LED LAN
3 RESET button (reset and pairing)
4 LAN port (RJ45 Ethernet)
5 Micro USB port
POWER DC5V 1A
6 Wall mounting hole
(back side, not illustrated)
7 Network cable
8 USB type A plug
˜ Technical data
Gateway
USB input voltage/current
Frequency band
Max. transmitted power
Communication protocol
Reception range/angle
Operating temperature
Operating humidity
Storage temperature
Measurements
Weight
24 GB/IE
9 USB cable
10 Micro USB plug
11 Metal pin
12 Screw (x2)
13 Dowel (x2)
14 Mounting template
15 USB power adaptor
Not illustrated:
16 Quick start guide
17 Safety instructions
5 V , 1 A
2.4 to 2.485 GHz
13 dBm
ZigBee 3.0
approx. 70 m/360° (free area)
+5 to +35 °C
10 to 70 %
0 to +45 °C
approx. 89 x 89 x 23.5 mm
approx. 78 g
