Tannoy PCI 5DC IW Schnellstartanleitung Seite 7

12 PCI 5DC IW / PCI 6DC IW / QCI 6DC IW
Product Feature Identifi cation
Grilles PCI 6DC IW
and QCI 6DC IW
PCI 5DC IW
Paint Masks PCI 6DC IW
and QCI 6DC IW
PCI 5DC IW
Cutout Templates
Product Feature Identifi cation
Optional PMK Pre-Mount Kit
PCI 5DC IW uses the PMK 5 IW
PCI 6DC IW and QCI 6DC IW uses the PMK 6 IW (shown below)
Frame
Mounting Brackets
Optional Back can
for PCI 5DC IW, PCI 6DC IW, and QCI 6DC IW
Screw holes for
PMK kit option
Acoustic Foam
Mounting Slots
(X10)
Quick Start Guide
Cable Entry
Loop for strain
relief of cable
13
