Product HANDBOOK
Nomenclature: [
DPX models as described below:
Unit Configuration Code: DPXa-bcde-f
Where:
a = Power rating (15, 20, 30,40 or 60).
b = Nominal input voltage (12, 24 or 48)
c = Input range, 2:1 omit designation: (for 12V nom: 9-18Vdc, for 24V nom: 18-36Vdc and for 48V
nom: 36-75Vdc).
Input range, 4:1 'W' designation: (for 24V nom: 9.5-36Vdc and for 48V nom: 18-75Vdc).
d = Number of outputs: S = single output, D = dual output, T = Triple output
e = Output voltage (3P3, 05, 5P1, 12, 15, ±5, ±12 or ±15)
f = Omit for Positive Logic Remote ON/OFF
N for Negative Logic Remote ON/OFF
Input Parameters:
Model Nominal Input
Voltage
12Vdc
DPX20
24Vdc
48Vdc
12Vdc
DPX30 24Vdc
48Vdc
12Vdc
DPX40 24Vdc
48Vdc
Model Nominal Input
Voltage
24Vdc
DPX15W
48Vdc
24Vdc
DPX20W
48Vdc
24Vdc
DPX30W
48Vdc
24Vdc
DPX40W
48Vdc
Input Connections: Screw terminal, use wire gauge 14 to 18AWG
Page 14 of 18
DPX Series
Input range Max Input current
2119mA
9.5 – 18 VDC
1031mA
18 – 36 VDC
513mA
36 – 75 VDC
9.5 – 18 VDC 3165mA
1543mA
18 – 36 VDC
762mA
36 – 75 VDC
4675mA
9.5 – 18 VDC
2250mA
18 – 36 VDC
1111mA
36 – 75 VDC
Input range Max Input current
787mA
9.5 – 36 VDC
18 – 75 VDC 387mA
1043mA
9.5 – 36 VDC
515mA
18 – 75 VDC
1623mA
10 – 40 VDC
791mA
18 – 75 VDC
2110mA
9.5 – 36 VDC
1042mA
18 – 75 VDC
2 :1 Input models
Input Fuse
6A
4A
4A
6A
4A
4A
8A
4A
4A
4 :1 Input models
Input Fuse
6A
4A
6A
4A
6A
4A
8A
4A
DPX Series, 17185 issue 02, April 2013
Fuse type
Slow blow
Slow blow
Slow blow
Fuse type
Slow blow
Slow blow
Slow blow
Slow blow
