Caliber RDD770 Kurzanleitung Seite 2

KEY
Short press
1 Mute
2 Power on
3
4 Audio menu
5 Mode
6 volume
7
8
9
10
11
12
13
14
15
16
17
19
20
21
Panel release
Power
Band
Mute
OK
AF
TA
PTY
Tune up/down
Menu (system)
Audio menu
Mode
AS
PS
volume
M1-M6
Pause/Play
INT
Repeat
Random
File/track down/up
Fast forward/backward
Seek up/down
3,5mm AUX in Jack
USB input
SD card input
reset (behind panel)
Downloaded from www.Manualslib.com
SYSTEM
Long press Short press
Power off
Menu
Seek down
Push this button to release the frontpanel
Power function to activate or deactivate the unit. To deactive press and hold the power button for 3 seconds
Band selection allows you to select different reception bands, f.i. FM1, FM2, FM3
Push this button to turn off the sound, push again to return to the last volume level.
Push this button to confirm the option you have selected.
AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse
TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode
you are in (DVD, CD, USB, SD) it will automatically interrupt the music and give the information, after that it automatically switches back to
the selected mode.
The PTY function allows you to search for stations with a particular program type like NEWS group and POP group both of these groups
are divided in different subjects. PTY "POP", pop/rock, easy/light, classics/others, jazz/country, nation/oldies. PTY "NEWS", news/info,
sport/educatie, culture/science, weather/finance, social/religion
Long press to move the radio frequency number up/down step by step.
Hold button for 3 seconds to open the menu. Press repeatedly to view menu items.
The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader.
These options can be used to fine tune your sound.
The mode button allows you to go from one source to another source (f.i. Tuner) by pushing the button as many times as needed.
AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations (M1-M6). Note: all previous stored stations are lost
PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the first preset (M1)
then it will go to the next and so on.
This allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears
These are the preset stations where you can store your favorite radio stations if in tuner mode
This button allows you in DVD, CD, USB or SD mode to play or to pause the music.
INT will play 10 seconds of each song on the DVD, CD, USB or SD. If the preferred song is playing, push again and it will play that song
Repeat will play a selected song or album continuously. Available in USB and SD mode
Shuffle will play all the songs random. Available in DVD, CD, USB and SD mode
In MP3 mode press this button to go up or down one folder.
Long press to fast forward. Available in DVD, CD, USB or SD mode.
Short press to move to the next station automatically
To connect an external audio system
When inserting a USB stick the unit will switch to USB mode. (Max 1000 tracks)
Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode.
Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.
Note! Do not operate the unit while driving.
manuals search engine
TUNER
Long press
Panel release button
3.5mm AUX in Jack
AF
TA
PTY
PS AS
M1 Memory 1
M2 Memory 2
M3 Memory 3
M4 Memory 4
M5 Memory 5
M6 Memory 6
Band
Tune down
Seek up Tune up
Description of the functions
CD/DVD/SD/USB
Short press Long press
Ok
Pause/play
INT
Repeat track
Repeat all
Random
track down -10
track up +10
File/track down Fast backward
File/track up Fast forward
