A.
B.
ADSL port -
connect to
ADSL line
Downloaded from www.Manualslib.com
Connecting the Modem to Your Computer
First, connect the power adapter to the
DSL-300T and then plug the other end of the power adapter to a wall outlet or
power strip. The Power LED will turn
Insert one end of the cable into the
DSL-300T and the other end of the cable to an
Ethernet port on your computer.
Ethernet port -
connect to
Ethernet cable
manuals search engine
receptor at the back panel of the
ON to indicate proper operation.
Ethernet port on the back panel of the
Ethernet Adapter
Factory
Reset
button
2
or available
Power input -
connect to power
adapter
