Fender® Hot Rod series amplifiers are employed on every stage in the world, large and small, by guitarists from all walks of life. Whether rockers,
punkers, pop stars or cowboys, they can all agree that Hot Rod amps deliver unmistakable Fender tone, a perfect platform for crafting your own
sound. These no frills amps are affordable, reliable, loud & proud. They respond extremely well to your favorite stomp boxes.
The Blues Junior is a 15-Watt, warm-toned, long time favorite, the perfect grab & go tube amp for stage or studio. It's got the fat mid tones
characteristic of EL-84 output tubes, warm 12AX7 preamp tube overdrive, real spring Reverb, simple control layout, footswitchable FAT boost, and
external speaker capability.
• Easier reading black control panel with front-reading text •
• New badge • • Vintage-sized jewel light •
frequency harmonic content
VOLUME
INPUT
5
4
3
2
1
A. INPUT Plug your guitar in here.
B. VOLUME
Adjusts preamp gain. Increase the Volume setting
to produce more distortion and sustain. Use lower Volume
settings to produce cleaner sounds.
C. FAT Press IN to boost preamp gain for extra distortion and
sustain.
Normal
You can use a footswitch (optional) to activate the FAT boost
remotely. See Footswitch {J} on page 7.
6 6
Downloaded from www.Manualslib.com
The world's most popular tube amps just got better.
Cosmetic and electronic upgrades include:
• • Rattle reducing shock absorbers for EL84 tubes
• Super sensitive Fender Special Design 12 inch "lightning bolt" speaker by Eminence® •
Specially selected
Limited 5-year warranty US and Canada, other territories may vary.
TREBLE
6 7 6 7
8 5 8
9 4 9
10 3 10
11 2 11
FAT
12 1 12
Fat boost
manuals search engine
• Heavy duty set screw "chicken head" knobs •
12AX7 and EL-84 tubes inside!

Control Panel

Control Panel
BASS MIDDLE
6 7 6 7
5 8 5 8
4 9 4
3 10 3
2 11 2 11
1 12 1 12
D. TREBLE / BASS / MIDDLE
E. MASTER
Use MASTER to adjust the volume of the amplifier after you
have set VOLUME for the desired level of preamp distortion.
F. REVERB
G. POWER INDICATOR
H. POWER SWITCH
fender.com
• • Vintage Fender "dog bone" handle
• Lower-noise shielding • • • "Sparkle" mod for enhanced high-
MASTER REVERB
6 7 6 7
5 8 5
9 4 9 4
10 3 10 3
2 11 2
1 12 1 12
Adjusts tone character.
Adjusts the overall volume output of the amplifier.
Adjusts the level of the Reverb effect.
Illuminates when the unit is ON.
Switches the unit ON/OFF.
ON
8
9
10
11
OFF
