User Manual Full HD Hybrid Set top box

5. LED Display

Set top box has a LED segment display.
It is a 4-digit 7 segment LED displaying channel names and program information.

6. Resolution / Display Format Setting

You can decide which resolution and Display Format to use according to the video output and your TV.
High definition television
The digital receiver supports various video resolutions from 576 to 1080. In general, a resolution of 720 or more
is considered high definition. The higher the resolution is, the better the quality is. However, if your television set
does not support high definition, you cannot enjoy high definition quality picture.
Set the Video Format option as you desire. If you set this option to 576P, the digital receiver will present even
high definition programs in resolution of 576. On the contrary, if you set it to 1080P, the digital receiver will
present even standard definition programs in resolution of 1080.
Audio and Video settings
You have to configure the audio and video settings
appropriately for your television set and other
devices. Go to the Menu > SYSTEM > System
Setting > Audio & Video Setting menu. Here you
will find options necessary to set up the audio and
video configuration of your Set top box.
Basically, there are two audio sources as you can
find two audio sockets on the back panel of the
digital receiver. You can enjoy only one source or
both of them in either stereo (Left/Right) or mono.
The digital receiver can output two types of digital audio signals via S/PDIF connector. One is an encoded signal
18
