4-bay RAID System with LCM Panel
nUMBER of DISkS SUPPoRtIng
EACh RAID MoDE
RAID Modes
RAID 0 (Striping)
RAID 1
(Mirroring)
Span
Clone
RAID 5
RAID 1+0
JBOD

hDD LED x 8

Indicator
Disk not detected
Disk detected
Disk not healthy
Data access
Disk
Rebuild
Downloaded from www.Manualslib.com
number of
Disk in RAID
2 to 4
2
2 to 4
2 to 4
3 or 4
4
1 to 4
Left (Connection/
Access)
None
White
White
Flash White
Source
White
HDD
Target
Flash White
HDD
RAID
Alert
manuals search engine
IB-RD3264+USE2

LED InDICAtoRS

Power LED x 1

Indicators
Power on
Power off

RAID Alert LED x 1

Indicators
Healthy
Rebuild
Broken
Degrade
Fan Error
hDD (1, 2, 3, 4)
Right (health)
None
None
Red
None
None
Blink Red
Blink Red
14
Color
Green
None
Color
None
Blink Red
Red
Red
Red
RAID mode
All modes
All modes
All modes
All modes
RAID 1, RAID 5,
RAID 1+0, Clone
