Specifications apply after 30 minute warm-up in an ambient of 5°C to 40°C
FREQUENCY
Frequency Range:
Setting Resolution:
Display Resolution:
Accuracy:
Stability:
Phase Noise:
Residual FM:
(FM Off)
OUTPUT LEVEL
Output Level Range:
Setting Resolution:
Accuracy:
Harmonics:
Non-Harmonic Spurii:
Carrier Leakage:
Output Impedance:
Output Connector:
Output Switch:
FM MODULATION
Peak Deviation:
Setting Resolution:
Modulation Frequency:
Deviation Accuracy:
External Modulation
Frequency Response:
Distortion:
Input Impedance:
Input Connector:
2
Downloaded from www.Manualslib.com
10 MHz to 1000 MHz
1 kHz by direct keyboard entry, or in user-set increments of 1kHz to
999.999 MHz by rotary control or increment–decrement keys.
1 kHz
± 2 ppm over the temperature range 5°C to 40°C.
<1ppm/year ageing.
<−110dBc/Hz at 25 kHz offset, 500 MHz carrier.
Equivalent peak deviation in a 300 Hz to 3.4 kHz bandwidth:
–127dBm to +7dBm (0.1µV to 500 mV into 50Ω).
0.1dB (or 0.01µV to 1mV) by direct keyboard entry, or in user-set increments of
0.1dB to 100dB (or 0.01µV to 100mV) by rotary control or increment–decrement
keys.
Better than ± 2dBm, except for output levels <–70dBm at 500 -1000 MHz,
± 3dBm.
Typically <–25dBc, maximum –20dBc, any carrier frequency, output level ≤0dBm.
≤ – 60dBc at ≥ 8kHz offset.
≤ 0.5µV generated in a 50Ω load by a 2 turn 25mm diameter loop, 25mm from
the generator, with the output set to ≤ –10dBm into a 50Ω sealed load.
50Ω
TYPE N
RF OUT on-off switch with LED showing ON status.
0.5 kHz to 100 kHz.
0.5 kHz by direct keyboard entry, rotary control or increment–decrement keys.
Internal 1kHz; External 300 Hz to 50 kHz
<±15% of setting ± 0.5kHz, excluding residual FM, for 1 kHz modulation, internal
or 1Vrms external.
± 1dB from 300 Hz to 50 kHz relative to 1 kHz.
<2% total harmonic distortion at 1 kHz modulating frequency, 100 kHz deviation
and 500 MHz carrier.
100kΩ
BNC
manuals search engine
12 Hz at 100 MHz carrier
25Hz at 500 MHz carrier
60 Hz at 1000 MHz carrier
