Hardware Description

The Front Panel
The front panel consists of LED Indications.
LED Indicators
Per Device: Power
Per Port:
Figure 1. Front panel view
LED Status Color
Power On
LINK/ACT Off
Figure 2. Back view
LINK/ACT (Link/Activity)
Green
-
Description
The switch is supplied with
suitable power.
The port is not linked
successfully with the device.
4
