Assembly
1 Flush through the supply pipes.
2 Place the mixer including the rubber sealing washer in position on the sink.
3 Slip the slide washer, washer and collar nut over the threaded base and tighten the
collar nut by hand. Tighten screws.
4 If necessary, shorten plastic hose according to the table and insert it up to the collar
into the shorter blue marked copper pipe.
max. permissible
water pressure on
the spot
in bars
1
1,5
2
3
4 5 6 7
5 Connect the shorter, blue marked supply pipe to the angle valve.
Connect the longer pipe to the storage tank and the short one to the T-fitting (see
drawing).
6 Connect the hose and mount the hose weight.
Attention!
With water heaters of 5 liters the flow rate at the mixer should not exceed 5 l/min.
In this case the flow rate must be reduced at the angle valve.
Operation
The mixer is actuated by lifting the lever head. Swivel to the left = hot water,
swivel to the right = cold water.
The handspray can be drawn approx. 50 cm out of the arm lining.
When the storage tank is being heated, the spout will drip.
When changing the spray former, it is imperative to use one made for this type of mixer.
GB
Hose lengths to be used
storage tank volume
8, 10 and 15 liters
without hose
hose to be short-
ened to 90 mm
hose unchanged,
reduce flow rate at the angle valve
up to 5 liters
hose to be short-
ened to 90 mm
hose unchanged
®
