Kress KI200 Handbuch Seite 12

5. Indirect measurement
The instrument can calculate the
distance using the Pythagorean theorem. This
function allows you to measure distances for
inaccessible locations.
Note:
1. All the points to be measured should be on
the same horizontal or vertical plane. In order
to get more accurate measurement results, it
12
is recommended to use a tripod to rotate the
instrument on the same axis for measurement
EN
(for example, the instrument's corner is fully
unwound against the wall for measurement).
Indirect measurement: Pythagorean
method two points
As shown in the figure below, measure the
height or width of a building, or when a height
needs to be determined by two distances, it
can be achieved by indirect measurement.
1
2
