Thank you for buying the babypushchair. Please remind users and guardians to read carefully before use. Please keep this manual properly. Failure to follow this
instruction may affect the safety of children.This manual should be kept in a safe and accessible place.
WARNINGS
• Assembly and adjustment of products must be performed by adults.
• Keep children away from moving parts.
• Ensure that all locking devices are locked.
• Seat belts must be used correctly.
• Any load placed on the handlebars will affect the stability of the pushchair
• To avoid harm to children, please keep plastic bags and other packaging materials away from children ！ Risk for Suffocation.
• The maximum weight of the pushchair is 15kg， No overloading.
• The maximum weight of the basket is 2kg， No overloading.
• If the pushchair is equipped with a rear luggage bag, its maximum bearing weight is 0.5kg， No overloading.
• This pushchair is suitable for age range: 0-36months.
• Do not use any accessories that are not supplied by the manufacturer.
• European standard: EN1888
1. PARTS
1. Canopy 2. Bumper 3. Bumper belt 4. Legs pad 5. Foot pad 6. Direction button 7. Front wheel 8. Handle 9. Canopy buckles 10. Folding hook 11. Backrest
adjustment 12. Basket 13. Rear brake 14. Rear wheel
2. OPENNING
Release the folding hook, hold the push handle with both hands, reverse open the frame, and then use step on the folding assembly and hear "click" to indicate opening in
place.
3. INSTALL REAR WHEEL
Insert the wheels into the into the wheel seat until you hear a click sound.
4. INSTALL FRONT WHEEL
Insert the wheels into the into the wheel seat until you hear a click sound.
5. INSTALL CANOPY
Put the plug into the tent when you hear "click" in the socket can be. Install the same way on the other side.
6. INSTALL FRONT BUMPER
Insert front bumper connector into the armrest seat hole inward and outward pull out, pull out Indicates that the installation is in place. Press the button outward. Pull out
and remove the front handrail.
7. USE OF SAFETY BELTS
Open: press the safety latch to the inside and pull outward and open it. Snap: insert the safet y latch plug (A) into the lock latch (B) unt il it reaches the butt on is clicked.
Shorten: lengthen the top band, then lengthen t he tail band and tighten. Lengthen: lengthen the top band, then shorten t he tail band and lock it .The cart must be
buckled when in use A cross the belt.
8. USE OF CANOPY. The tent was buttoned down open the awning. Lift the awning buckle to close the awning.
9. USING PARKING DEVICE. Press the left and right brake pedal, the stroller is locked. Otherwise release the brake pedal, the stroller is unlocked.
10. LEGS PAD ADJUSTMENT. Put your hands on your legsIndex finger pulls adjustment piece to be able to adjust a leg to rely on point of 1. 11. BACK ANGLE ADJUSTMENT.
Press down hard on the body Back to back adjustment buttons on both sides, forward at the same time push or pull back to adjust backrest angle.
12. FRONT WHEEL ORIENTATION AND DIRECTION. Press the front wheel button into the slot to actived. Lift up the orienting button to release.
13. PUSH HANDLE ROTATION. As shown, press push to adjust the button, you can rotate the knob.
14. USE OF TOP VIEW. Roll up and look up at the sky curtain, can look after the baby from the top every move.
15. FOLDING. Remove the bumper. First release the locking device and then step down. Release second locking device and push the handle until the stroller has been
folded.

16. MAINTENANCE

Fabric parts: 1. The fabrics must be cleaned with warm water and mild soap. Completely dry before you use it. If is absolutely forbidden to fold it and store it before it is
completely dry.
2. Do not use strong cleaning agents, bleach or agents with abrasive particles, in order to clean the product. It is forbidden to clean it in a washing machine, dryer, dry
cleaning, bleach and tumble-dry it.
Plastic and metal parts
1. The plastic and metal parts must be cleaned with a damp soft cloth and dried with dry soft cloth.
2. Do not let the product exposed to the harmful effect of external factors - direct sunlight, rain, snow or wind. This may lead to damage of the metal and plastic parts and
fading of the fabrics.
3. When you are not using the product, store it at a dry and well ventilated place, not in dusty, humid premises with very high or very low room temperatures.
ENGLISH
