Connecting to a DVD Player

If you want to connect a DVD player to your TV, you
can use the connectors of the TV set. DVD players
may have different connectors. Please refer to your
DVD player's instruction book for additional information.
Power off both the TV and the device before making
any connections.
Note: Cables shown in the illustration are not
supplied.
• If your DVD player has an
connect via HDMI. When you connect to a DVD player
as illustrated below, switch to the HDMI source. See
"Input Selection" section.
• DVD players can also be connected through
COMPONENT SOCKETS. YPbPr can be used only
when you connect a device that has a YPbPr output
through the PC input with YPbPr to PC cable (YPbPr
cable is not supplied).
• You may also connect through the SCART sockets.
Use a SCART cable as shown below.
Note: These three methods of connection perform the
same function but in different levels of quality. It is not
necessary to connect by all three methods.

Remote Control Handset

Inserting Batteries

• Remove the battery cover located on the back of
the handset by gently pulling backwards from the
indicated part.
• Insert two AAA/R3 or equivalent type batteries
inside. Observe the correct polarity (+/-) when
inserting batteries and replace the battery cover.
Note: Remove the batteries from the remote control
handset when it is not to be used for a long period.
Otherwise it can be damaged due to any leakage of
batteries. Remote range is approximately 7m/23ft.
A02_MB62_[GB]_woypbpr_IDTV_NICKEL17_3902UK_32970WLED_10075297_50199916.indd 43 A02_MB62_[GB]_woypbpr_IDTV_NICKEL17_3902UK_32970WLED_10075297_50199916.indd 43

To Switch the TV On

•
•
•
•
HDMI socket, you can
•
Note: If you switch on your TV via P+ or P- buttons on
the remote control or on the TV set, the programme
that you were watching last will be reselected.
By either method the TV will switch on.

To Switch the TV Off

•
•
Note: When the TV is switched to standby mode, the
standby LED can blink to indicate that features such
as Standby Search, Over Air Download or Timer is
active.
Once you have connected external systems to
your TV, you can switch to different input sources.
Press "SOURCE" button on your remote control
consecutively for directly changing sources.
English - 43 -

Switching On/Off

Connect the power cord to the 220-240V AC, 50
Hz.
Press STANDBY touch button. Then the standby
LED lights up.
To switch on the TV from standby mode either:
Press the " " button, P- or P+ or a numeric button
on the remote control.
Press the -P/CH or P/CH+ touch button on the TV.
The TV will then switch on.
Press the " " button on the remote control or hold
the on the TV until shut down, so the TV will switch
to standby mode.
To power down the TV completely, unplug the power
cord from the mains socket.

Input Selection
