Replacing the battery

1. Open the device.
2. Remove the flat battery and press the Learn/Test switch twice to discharge the device completely.
3. Insert the new CR123A lithium battery in the housing, respecting the correct polarity.
4. Close the device.

Technical specifications

Smoke detection: in photoelectric chamber
Power supply: 1 battery CR123A 3V
Battery life: 10 years
Two-way radio frequency: 868 MHz
Sound level of the internal siren: 85dB/3m
Working temperature range -10°C – +45°C
Dimensions: 30 mm X 70 mm X 70 mm
Weight: 100g
EN14604 certified
Hereby, URMET S.p.A. declares that the radio equipment type: SMOKE DETECTOR SD600 is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.elkron.com.
DS80SD8Z-002
