TABLE 1
CONDITION
Learning phase on the control unit after inserting
the battery
Start of detector calibration after the end of
initialisation or after pressing the Test button for
10 seconds for recalibration
Calibration procedure OK
Calibration procedure FAILED
CONDITION
* Press the test button: transmission/reception
with control unit OK
* Press the test button: transmission/reception
with control unit FAILED
* Press Test button: operation OK
Press test button: optical chamber fouled or out
of service
The battery is running out
Flat battery
CONDITION
Smoke detection alarm
Press Test button after 1 minute from the alarm
Press Test button within 1 minute from the alarm
End of 9 minutes after alarm detection and with
smoke below threshold
Detector out of service or optical camera fouled
* These tests are performed in sequence whenever the Test button is pressed
Installation
1.
Locate the installation location where the device is correctly accessible from the control unit (perform a preliminary test).
2.
Use the holes in the base of the device as a template.
3.
Fix the device with screws and anchor bolts.
4.
Refer to the side marks shown in figure A to align the holes in the sensor with the fasteners on the base. Insert the
sensor into the base.
5.
Turn the sensor clockwise to lock it as shown in figure B.
Maintenance
During normal operation, the detector can signal the need for maintenance by flashing the amber LED; a signal will also be sent to
the control unit. In this condition, the detection chamber must be cleaned using a dry cloth or a thin brush to restore proper
operation. The maintenance frequency depends on the environmental conditions in which the detector is installed.
8
INITIALISATION / LEARNING
LED INDICATION
RED
RED
AMBER
LED INDICATION
RED
RED
RED
AMBER
RED/AMBER
ALARM DETECTION AND BUZZER SILENCING
LED INDICATION
RED
RED
RED
AMBER
(Figure A)
LED FLASHES
Every two seconds for 1
minute
Every two seconds for 1
to 9 minutes
Intermittent
NORMAL OPERATION
LED FLASHES
Fast flashes for 1 second
Three flashes
Fast flashes
Every 45 seconds
Every 4 seconds.
LED FLASHES
Fast
Continuous for 9 minutes
Continuous for 9 minutes
Stops flashing
Every 5 seconds.
(Figure B)
BUZZER
Two short beeps
One beep
Two-tone alert
Intermittent sound
BUZZER
Three tones
No sound
Low intensity
continuous beeps
BUZZER
Intermittent sound
Stops sounding for 9
minutes
Stops sounding at the
end of the minute
Two beeps
