Durable 5087 Montageanleitung Seite 28

Inhaltsverzeichnis

Werbung

Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 1
EN
English
Note:
Please contact our service team if one of the parts are
missing or damaged.
Assembly
– Take all parts out of the packaging.
Table-top mounting table clamp (product variant # 5087)
▶ siehe Abbildung 4
– Slide the table mount (6) until it meets the table edge.
– Tighten the clamping screw (7) with the enclosed Allen key.
Table-top mounting with cable hole
(product variant #5088)
▶ siehe Abbildung 5
WARNING!
Risk of property damage!
Take care not to clamp in or squeeze any cables.
– Feed the cable through the hole in the table plate and the ope-
ning provided for the purpose in the table mount (8).
– Feed the clamping screw (10) through the pressure plate (9) into
the table mount (8) and secure it with the enclosed Allen key.
28
