Description
1. MODE button
2. CLEAR button
3. " Favourite " button
4. Preset Master button
Ø8 or 3/8"
5. Clamping shaft
6. Contact point Ø2 / M2.5 or 4-48-UNF
7. Lifting cap
8. Slot for Proximity cable
9. Slot for battery or Power Cable
10. Low battery
11. + / - Indicator
12. Keypad lock
13. 6-digit display
14. Hold measured value
15. Send data
16. Measurement units mm / INCH
17. Preset mode
18. Analogue scale
19. Lower limit exceeded
20. Upper limit exceeded
21. Tolerance indicators
22. Analogue scale lower limit
23. Analogue scale upper limit
24. Active REF (1-4)
25. Tolerance mode indicator
26. Int-Ext indicator for MIN function (CBG mode)
27. Multiplier
28. Bluetooth
connection
®
29. Int-Ext indicator for MAX function (see chap. 12.1)
