Parts list

Part No.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Front support leg
Rear support leg
Seat frame
Backrest frame
Seat support post
Backrest support post
Adjustable support frame
Main connecting axle ø20 x 167L
Front support leg axle ø20 x 85L
Backrest support axle ø15 x 279L
Seat support axle ø15 x 196L
Backrest connecting axle ø15 x 124.5L
Seat connecting axle ø15 x 77.5L
Safety pin ø33 x ø12.7
Washer ø46 x T5.0
Washer ø32 x T5.0
Seat T50 x 300 x 350
Backrest T50 x 300 x 755
Bushing ø46/ø42 20 x 13
Bushing ø32/ø28 15 x 13
Bushing ø32/ø28 20 x 13
Round snaplock
Snaplock
Round outer cap ø60
Footcap ø60 x 1.5
Square inner cap 50 x 1.5
Square inner cap 20 x 40 x 2.0
Screw M8x65
Screw M8x30
Screw M6x25
Screw M6x20
Screw M8x25
Screw M5x35
Nut M5
Washer ø8,5 x ø16 x T1.5
Washer ø6,5 x ø12 x T1.0
U-shaped push lever
Fabric band T1.5 x 20 x (460)
Spring
Washer ø46 x ø20.1 x T1.0
Description
17
Q'ty
1
1
1
2
1
1
1
1
2
1
1
1
1
1
4
6
1
1
10
8
4
1
1
2
2
1
2
4
4
2
4
10
1
1
8
4
1
1
1
2
