System Map: Bottom & Rear Views
Overheating
To prevent your computer from overheating make sure nothing blocks any
vent while the computer is in use.
Bottom Cover Removal Warning
Do not remove any cover(s) and/or screw(s) for the purposes of device
upgrade as this may violate the terms of your warranty. If you need to
replace/remove the hard disk/RAM etc., for any reason, please contact your
distributor/supplier for further information.
Control Center
Run the Control Center from
the Start menu in Windows. You
can also press the Fn + Esc key
combination, or double-click
the icon
in the notification
area of the taskbar to access
the Control Center. The Control
Center provides quick access to
Power Modes, Fan settings, LED
Keyboard configuration and the
Flexikey application.
1.
Vent
2.
Battery
3.
Subwoofer
4.
Speakers
5.
Thunderbolt 3 Port
6.
Mini DisplayPorts 1.4
7.
HDMI-Out Port
8.
RJ-45 LAN Jack
9.
DC-In Jacks
10.
Lightbar
Figure 5 - Bottom & Rear Views
Figure 6 - Control Center
EN
11
