3. TYPICAL APPLICATION MULTIPLE PC INTERNET ACCESS

INTERNET
ADSL
Xplorer 870
IP: 192.168.1.2
Subnet: 255.255.255.0
Gateway: 192.168.1.1
LAN
IP: 192.168.1.1
Subnet: 255.255.255.0
IP: 192.168.1.4
Subnet: 255.255.255.0
Gateway: 192.168.1.1
IP: 192.168.1.5
Subnet: 255.255.255.0
Gateway: 192.168.1.1
56 56 56 56 56 56 56 56
IP: 192.168.1.3
Subnet: 255.255.255.0
Gateway: 192.168.1.1
hub/switch
