half an hour. The unit will be operated at speed 1 at the end or will be tur-
ned off by the timer if set.
4. TIMER: Press the timer button to set the timer between 1 and 12 hours, the
corresponding time will be shown on the display and the "H" indicator will
light up.
5. HORIZONTAL (LEFT AND RIGHT) SWING: Press the horizontal swing button to
make the vertical louvers swing, press the button again to stop this function.
6. VERTICAL (UP AND DOWN) SWING: Press the vertical swing buttom to make
the horizontal louvers swing, press the button again to turn off the function.
7. COOL: Press the cool button to start the cooling function.
Note: If the water tank is empty, you need to refill it and then restart the unit.
8. TEMPERATURE DETECTION: The temperature will automatically be displayed
when the cooler is turned on.

CLEANING AND MAINTENANCE

1. Warning: Please shut off the unit and unplug before cleaning.
2. Outer filter, wet curtain assembly cleaning: If there is foreign matter is atta-
ché on the filter, the wind will be influenced. Clean the filter wet curtain
assembly at least once a month. Remove the wet curtain in order, use deter-
gent and soft brush, soak with detergent for a few minutes, wash and dry the
wet curtain.
3. Tank cleaning: Unplug the power cord, turn the water tank knob to the hori-
zontal direction, pull out the water tank and wipe the water tank with pro-
per detergent
4. Please use wet cloth to clean the product housing. Do not use water to rinse
the unit. Do not use abrasive cleaning liquids or chemical agents to clean the
product.
5. Installation after cleaning: Install the filter, wet curtain assembly, water tank
and other components in sequence, make sure the installation is correct, plug
in the power, and confirm that the product is working properly.
6. Maintenance: When the product is not used for a long time, unplug the
power plug, package the product and prevent dust from entering the body;
ensure that the wet curtain and the filter are dry before installation, and
there is no water in the water tank; after packaging, store in a dry and venti-
lated place
Filling notice
1. Fill the water in line with water level. Unplug the unit during refilling.
