Removing/replacing accumulator
Attention ! When removing/replacing the accumulator, the selector switch must
be in position
Use only original WAGNER accumulator batteries. Avoid short-circuiting the
accumulator wires. When replacing spare parts or accumulators, be careful of
sharp edges which can cause injury or which can damage the cables. Do not pull
on the cables of the solar module.
• Set the selector switch (fig.
• Separate the solar station from the stand.
• Loosen the four cross-recess screws on the back (fig
• Place the covering frame with solar panel carefully to one side, as far as this
• Carefully remove the plus and minus poles from the accumulator.
• Remove the accumulator from the housing.
• Reconnect the plus pole (red wire) and minus pole (black wire) with correct
☞
Note: Observe plug size. Different sized plugs prevent wrong polarity of the connec-
tions to the accumulator.
CHARGING UNIT / EXTRA ACCESSORIES
In order to charge the solar lamp over a longer "period of bad weather", we recom-
mend the WAGNER mains charging unit. With this the solar lamp can be charged di-
rectly from the mains electricity supply. Charging duration approx. 24 hours. Make sure
that the operating switch is set to
the charging socket.
You can purchase the following extra accessories from the WAGNER range for the so-
lar lamp:
WAGNER mains charging unit Europe
WAGNER mains charging unit GB
WAGNER mains charging unit AUS
Extension
(to increase the height of the lamp by approx. 220 mm)

Spare parts

Accumulator battery NiCd 4.8 V / 2200mAh
Electronics solar station
LED board
Connection cable 5m
Changing connection cable see fig.
Downloaded from www.Manualslib.com
socket on the solar station.
is permitted by the length of cable.
polarity to the accumulator.
manuals search engine
0
.
) to position
0
. The connection socket of the lamp unit serves as
Item no. 3751 210
Item no. 3751 211
Item no. 3751 212
Item no. 1015 702
Item no. 1016 700
Item no. 1016 338
Item no. 1016 335
Item no. 1016 332
Remove the plug from the
).
