Kicker Q-CLASS 8L7 Benutzerhandbuch Seite 5

Paralleled Voice Coils, Woofers in Parallel
Dual 2Ω Voice Coils in Dual Subwoofer confi guration = 0.5Ω Load
Dual 4Ω Voice Coils in Dual Subwoofer confi guration = 1Ω Load
amplifi er +
WARNING: If you are using multiple subwoofers that are wired in series to one another, each subwoofer must be in a separate chamber. If not, the
subwoofers could become damaged, resulting in loss of warranty.
amplifi er -
Series Voice Coils, Woofers in Parallel
Dual 2Ω Voice Coils in Dual Subwoofer Confi guration = 2Ω Load
Dual 4Ω Voice Coils in Dual Subwoofer Confi guration = 4Ω Load
amplifi er + amplifi er -
