periods of storage without overcharging or damaging the battery.
6) The CT15AMBCM has four external holes for mounting. Mount the charger in a desired
location with equipped self-drill screws. It is important to keep in mind the distance to the
battery.
7) Following is the charger's technical specification:
AC Input
DC Output
Charger Type
Start Voltage
Housing Protection
Battery Type
Battery Capacity
Accessories Included
Ambient Temperature

CONNECTING TO THE BATTERY

1) Identify polarity of battery posts. The positive battery terminal is typically marked by
these letters or symbol (POS,P,+). The negative battery terminal is typically marked by
these letters or symbol (NEG,N,-).
2) Do not make any connections to the carburetor, fuel lines, or thin metal parts.
3) Identify if you have a negative or positive grounded vehicle. This can be done by
identifying which battery post (NEG or POS) is connected to the chassis.
4) For a negative grounded vehicle (most common): connect the RED POSITIVE clamp
first to the positive battery terminal, then connect the BLACK NEGATIV clamp to the
negative battery terminal or vehicle chassis.
220-240VAC, 50-60Hz, 2.5A
12VDC, 15A;
24VDC, 7.5A;
12VDC, 20A (300 seconds)
Temperature Controlled
8 steps, Full-automatic Charging Cycle
> 1V
IP33
All Types of 12V &24V Lead-acid Batteries,
and 12V Lithium Ion Batteries
50-200Ah (24V), 50-400Ah (12V),
Maintains All Battery Sizes
Clamp Connectors, 12V Cigarette Lighter
Plug, 12V SUPPLY Cigarette Lighter Outlet,
Screws
0℃ ~ +40℃
