OVERVIEW
1
3
7
8
1. MAIN LEVEL CONTROL
Controls the overall output volume (subwoofer
and speakers).
2. SUB LEVEL CONTROL
Controls the output volume of the subwoofer.
3. SUB PHASE
Shifts the phasing of the subwoofer by 180°. (Use
this function if the speakers and subwoofer are
creating the effect of cancelling each other out).
4. BLUETOOTH PAIRING BUTTON
Used to pair the HiCast S84 with other Bluetooth
enabled devices (See Bluetooth Connection
section)
5. INPUTS
Connect external devices using either the XLR
(balanced), 6.3mm Jack (balanced) or RCA
Phono inputs (unbalanced).
6. OUTPUTS
Connect the first pair of speakers using the NL4
Speakon output.
HiCAST S84
4.1 PA SYSTEM
CAUTION
RISK OF ELECTRIC SHOCK
DISCONNECT INPUT POWER
BEFORE OPENING. Ta=40°C
WARNING: THIS APPLIANCE MUST BE EARTHED
AC INPUT:
FUSE:
100~120V~50/60Hz
100-120V T6.30AL 250V
220~240V~50/60Hz
220-240V T3.15AL 250V
POWER CONSUMPTION: 400W
SUBWOOFER POWER: 250W
SERIAL NO.
MAIN LEVEL
R
SUB PHASE
0°
180°
INPUT
RIGHT
OUTPUT
2 x 40W at 4Ω
RIGHT
ON
OFF
VOLTAGE
110-120V~
220-240V~
7. POWER SWITCH
Turns the PA On or Off. (Ensure the Main Level is
turned down fully before turning on or off).
FULL RANGE
INPUT
8. VOLTAGE SELECTOR
Change the Input voltage (please check the
correct voltage for your region before altering
HiCAST 4A
the voltage switch).
+
—
9. AC INPUT WITH FUSE HOLDER
Connect the supplied UK or EU power cable to
the AC Input.
6
SUB LEVEL
L
LEFT
LEFT
AC INPUT
FULL RANGE
THRU
40W @ 8Ω
—
+
2
4
5
6
9
