User Manual (EN)
Analogue radio alarm clock with additional digital display
Commissioning:
1.
Open the battery compartment and insert a Mignon/AA/1.5V alkaline battery. Make sure the polarity is correct.
2.
The hands will now move to the radio signal reception position. The alarm will then start searching for the radio signal.
3.
After about 5-10 minutes (depending on how fast the radio signal is received), the hands will adjust to the correct time.
Now the display of temperature and date alternates in the LCD field.
Manual time setting:
If the watch does not receive a radio signal, press and hold M.SET for 3 seconds to move to manual time setting. Now you can set
the correct time using this button. The LCD display will synchronize with the analog display. However, if you are within the range of
the radio signal, the watch will automatically try again to get the radio signal to display the correct time.
Start manual reception:
When the clock is running, press the REC button for 3 seconds. The hands move to the 12:00 position. Now the watch starts to
search for the DCF signal. If no signal is received, the watch will display the previously stored time.
RESET function:
1.
If for any reason the clock is not set correctly, you can perform a "Reset".
2.
Use a metal object (e.g. a needle) and press the "Reset" button on the back of the movement to short the watch.
3.
All hands move to the 12 o'clock position.
4.
After about 5-10 minutes (depending on how fast the signal is received), the hands automatically adjust to the correct time.
Set the alarm:
Press the button with the alarm symbol in the lower left corner for 3 seconds until the time display flashes. Use the + and - buttons
to set the desired hour and press the button with the alarm symbol again to confirm. The minutes will now flash on the display. This
can also be set with the + and - keys and confirmed with the alarm symbol key.
Repeat alarm & light:
1.
Press the SNOOZE/LIGHT button on the top of the watch to activate the backlight and temporarily stop the alarm.
2.
After about 4 minutes, the alarm will sound again.
Enable/disable alarm:
1.
Slide the Alarm ON/OFF switch to the ON position to turn the alarm on. The display shows a bell symbol above the alarm
time and a coloured dot. In addition, an alarm level indicator appears on the dial.
2.
Slide the Alarm ON/OFF switch to the OFF position to turn off the alarm. The display shows a crossed-out bell symbol
above the alarm time.
Technical data:
Integrated radio receiver to receive the DCF 77 time signal:
1.
Operating voltage range: 1.25 - 1.75 V
2.
Max. temperature range: -5 to +50 °C
3.
Current consumption:
4.
Max. battery life:
5.
Battery type:
Possible sources of interference:
1.
Household appliances
2.
Televisions less than 2m apart
3.
Machines with HF stray fields
4.
At a greater distance from the transmitter (approx. 1,500 km and more). Due to the special propagation of long waves,
topographic and meteorological conditions may impair reception.
Disfunction:
1.
Hands do not move after battery insertion
2.
Watch does not adjust to the correct time because it has not received a radio signal within 10 minutes of inserting the
battery.
Steps:
1.
Check battery voltage, battery contact and correct polarity
2.
Move the watch to another location, such as near a window or by turning the watch 90 degrees.
3.
Remove the battery and reinsert it after a few minutes.
4.
If the transmitter is faulty, wait a few hours and repeat the starting procedure.
150uA
> 1 year
Alkaline
1848
