ENGLISH _____________
Includes
Micro Player™, removable joystick, CO/VS™ cable and user guide
Materials needed (not included)
4 AA batteries or Micro-USB charge cable
Please read and follow this user guide thoroughly before use.
5 6 7
1. Removable joystick
2. RESET button
3. On/o button
4. COIN button
1
5. Volume up button
8
6. Headphone port
7. Volume down button
8. Battery cover
9. Power port (5V IN)
10. CO/VS™ port
2 3 4
11. Directional pad
12. START button
9 10
13. SHOOT button
14. JUMP button
12
11
13 14
