sided adhesive supplied without damaging the QR code (FIG.
B-3).
3.2 INSTALLATION OF THE APP (FIG. C)
- Search and download the "Battery Link" APP from "Google
Play" (Android 4.4 devices and higher version) or from the
"App Store" (Apple iOS 7.0 devices).
- Con gure the user (only for the rst installation) registering
via e-mail and Password.
- Add the device in use reading the QR code on the back of the
device (FIG. C).

4. OPERATION

- Open the APP on the mobile device and select the Battery
Link in use.
- Display the current status of the battery and voltage
performance to the terminals over time.
SPECIFICATIONS: BATTERY LINK
Device connectivity:
- Bluetooth 4.0, power class LE
Use distance:
- 10m
Use voltage:
- from 7V to 32V
Absorbed current:
- 1mA max
Protections:
- polarity inversion.
- 5A fuse.
Connection cables and terminals:
- terminals with 6mm RED (+) and BLACK (-) eyelet.
- cable section 0.5mm
- cable length 650mm
Dimensions:
- 69x45x15 (LxWxH).
Weight:
- 50 g
Accessories included (FIG. A):
- fastener ties (FIG. A-5).
- fastener double-sided adhesive (FIG. A-6).
.
2
- 6 -
