Fig. 1
Confi guring the QSS for
Coaxial Operation
Steps 2–6
tweeter lead
wires
QSS crossover
INPUT jumper.
Install only for 2-way confi gurations;
do not install if bi-amping.
tweeter output-level jumpers.
One of these jumpers MUST be installed. Higher
numbers mean more volume from the tweeter.
4
2014 QSS Multilingual Rev C.indd 4 2014 QSS Multilingual Rev C.indd 4
Step 1
coaxial mounting adapter
tweeter post
Fig. 2
Step 7
tweeter
+3 dB
0 dB
