Operation - Euromate 107439 Originalbetriebsanleitung

GB

Operation

Check before switching on!
DANGER! Risk of injury! The unit may
only be put into operation if no defects are
found when it is checked. If a part is defec-
tive, it must be replaced before the machine
is used again.
Check to make sure the unit is in a safe operating
condition:
– Check to make sure there are no visible defects.
– Check to ensure that all switches have been set
to [0], before plugging the unit into the power
socket.
Heating Prepare
Set time
– Before turn on the wall mounted heater, set the
time as right time. Press remote control [Lock]
button, light on control panel, it shows current
Room temperature.
Week
– Press [Set] button one time, [I/W] lights on,
press [–+] two buttons set the week from 1–7
(1 = Monday, 2 = Tuesday... 7 = Sunday etc.)
Hour
– Press [Set] button again, [I/H] lights on, [–+] two
buttons set the Hours from 01–00 (01 = 1 o'clock,
02 = 2 o'clock... 00 = 24 o'clock etc.)
Minute
– Press [Set] button again, [Fan/M] lights on, [–+]
two buttons set the Minutes from 00–59 (01 = 1
Minute, 02 = 2 Minute etc.)
Note: Press [Set] button, screen shows
number will twinkle 5 seconds, you should
operate in time, otherwise appliance will get
back to standby. (Appliance will keep the
right time until power off)
General Using Operation
– Turn the wall mounted heater on by pressing
the [ ] main button, the unit will blow the cold air
and [Fan/M] light is on.
– Pressing the [MODE] button, the unit will blow
the warm air and both [I/W] [Fan/M] lights are
on.
– Pressing the [MODE] button second times, the
unit will blow the hot air and both [I/W] [Fan/M]
lights are on.
– Pressing the [MODE] button Three times, the
unit will blow the cold air and [Fan/M] light is on.
Note: Control panel and remote control are
same operate way.
24H Timer Function
– Open the appliance as working conditions, (fan,
warm, hot are all ok). Control panel [TIMER] but-
ton and remote control [24H] button are same
operate way.
– Press [TIMER] button, set the timer up to 24
hours, keep press [TIMER] button to increase
the hours from 00–24 (00 = close, 01 = 1hour,
02 = 2 hours... 24 = 24 hours ect.) and
the [TIMER] light is on.
14
Note: set as [00] means no set timer,
the [TIMER] light is off.
Termostat Instructions
– Open the appliance as working conditions, (fan,
warm, hot are all ok). This function only through
by Remote control.
– To adjust temperature, press the [–+] to set the
desired temperature and the temperature set
from 10 °C to 49 °C.
• When the air temperature drops 2 degree below
the set temperature, the wall mounted heater will
start heating with [I/W] (1000W).
• When the air temperature drops 4 degree below
the set temperature, the wall mounted heater will
start heating with [I/H] (2000W).
• When the air temperature is ≥ the set tempera-
ture, the heater will blow cold air.
Week Timer Function
– Open the appliance as working conditions, (fan,
warm, hot are all ok). This function only through
by Remote control.
Week
– Press [W·Timer] button 1st time, [I/W] and [W-
Timer] are lights on, show [1] means [Monday].
Hour
– Press [W·Timer] button 2nd times, [II/H] lights
on, [–+] two buttons set the Hours from 01–00
(01 = 1 o'clock, 02 = 2 o'clock... 00 = 24 o'clock
etc.)
Minute
– Press [W·Timer] button 3rd times, [Fan/M] lights
on, [–+] two buttons set the Minutes from 00–59
(01 = 1 Minute, 02 = 2 Minute etc.)
• This is open time
Hour
– Press [W·Timer] button 4th times, [II/H] lights
on, [–+] two buttons set the Hours from 01–00
(01 = 1 o'clock, 02 = 2 o'clock... 00 = 24 o'clock
etc.)
Minute
– Press [W·Timer] button 5th times, [Fan/M] lights
on, [–+] two buttons set the Minutes from 00–59
(01 = 1 Minute, 02 = 2 Minute etc.)
• This is close time
• The above are finised set Monday Timer.
– Press [W·Timer] button once more, [I/W] lights
on, show [2] means [Tuesday]. Pls noted that
the operate with open time Hour/Minute and
close time Hour/Minute are all same as before
Monday.
– From 1-7 (1 = Monday, 2 = Tuesday... 7 = Sun-
day etc.) are all set finished, press [Delay] button
on remote control 7th times to set from Monday
to Sunday's temperature and press [–+] two but-
tons, select the temperature which you need, the
temperature range from 10 °C to 49 °C.
Note: In Week timer function, when you set
today's temperature, the thermostat func-
tion will start, the rules same as Thermostat
Instructions, pls noted.
