7.2 Using the function button

The gimbal always starts in pan mode. Press the
button once to go to lock mode. Press the button
twice to go to pan and tilt mode (regardless of which
mode you are currently in). If you are in pan and tilt
mode, go to lock mode by pressing the button once,
and from there, press it again to go to pan mode. If
you want to go directly from pan and tilt mode back
to pan mode, you can do this pressing the button a
fourth time.

7.3 Modes

- Swivel mode: The camera can be moved left or right.
- Swivel and tilt mode: The camera can be moved left and right as well as up and down.
- Lock mode: The camera remains rigid. All movements are blocked.

7.4 Mounting options: e.g. for taking shots near the ground

Portable
Installation
24
Downloaded from www.Manualslib.com manuals search engine
Press button once Swivel mode / lock mode
(by pressing again)
Press button twice Swivel and tilt mode
Press button three times 180° rotation mode
Press button four times Reset
Hold the button down Standby mode
more than 1 sec.
Hold the button down Switches the gimbal off
more than 3 sec.
Red LED lights up Switch off
!
Handheld
Disassembly
Dual Handheld
Installation
Please locked hand
grip after installation
