CpuFAN, SySFAN: Fan power Connectors
the fan power connectors support system cooling fans with +2V. If the main-
board has a System hardware Monitor chipset on-board, you must use a specially
designed fan with a speed sensor to take advantage of the Cpu fan control. re-
member to connect all system fans. Some system fans may not connect to the
mainboard and will instead connect to the power supply directly. A system fan can
be plugged into any available system fan connector.
SAtA~4: SAtA Connector
this connector is a high-speed Serial AtA interface port. Each connector can con-
nect to one Serial AtA device. Serial AtA devices include disk drives (hd), solid
state drives (SSd), and optical drives (Cd/ dVd/ Blu-ray).
IMportANt
* please do not fold the SAtA cable at a 90-degree angle. data loss may result
during transmission otherwise.
* SAtA cables have identical plugs on either sides of the cable. however, it is
recommended that the flat connector be connected to the mainboard for space
saving purposes.
CpuFAN SySFAN
MS-7733
2
