Block Diagram PUC2 Mic LEA
This PUC2 Mic LEA block diagram gives a detailed overview of PUC2 Mic LEA's
internals in PC/USB Mode.
Auto
AES3
Input
Decoder
A/D
Conv
AES3/SPDIF
Digital In
USB
LEA Engine
Level Enhanced
Automation
A/D
Conv
2
1
Mic Inputs
monitor
mix
DAC DAC
H/P Out Speaker Out
Analog OutputsD
AES3
Output
Decoder
AES3
igital Out
