Bosch FAA-MSR 420 Installationsanleitung Seite 2

Detector Base with Relay
Graphics
120 mm
100 mm
2 x 5
2 x
4,5 x 25
Figure 1.1:
Bosch Sicherheitssysteme GmbH
FAA-420-SEAL
1
Novodur
2
3
FAA-420-SEAL
8 mm
Installation Guide
FAA-420-SEAL
2016.06 | 4.0 | F.01U.003.288
Graphics | All 2
