Appearance & Interface Description:
1. Quick Release Plate Lock
2. Mounting Plate
3. Handle Lock Knob
4. Handle
5. Pan Head Locking Knob
6. Center Column Adjustment Lever
7. Grip Handle
8. Telescopic Legs
9. Center Column Lock
10. Gravity Hook
Operation Instructions
1. Installation and Removal Of Mounting Plate
• Press the safety button.
• Slide out the Mounting plate.
