janitza UMG 511 Bedienungsanleitung Seite 41

Adresse Format
5920 float
5922 float
5924 float
5926 float
5928 float
5930 float
5932 float
5934 float
5936 float
5938 float
5940 float
5942 float
5944 float
5946 float
5948 float
5950 float
5952 float
5954 float
5956 float
5958 float
5960 float
5962 float
5964 float
5966 float
5968 float
5970 float
5972 float
5974 float
5976 float
5978 float
5980 float
5982 float
5984 float
5986 float
5988 float
5990 float
5992 float
5994 float
5996 float
5998 float
6000 float
6002 float
6004 float
6006 float
6008 float
6010 float
6012 float
6014 float
6016 float
6018 float
6020 float
6022 float
6024 float
6026 float
6028 float
6030 float
6032 float
6034 float
6036 float
Bezeichnung
_ULL_UNDER_AVG_MAX[0]
_ULL_UNDER_AVG_MAX[1]
_ULL_UNDER_AVG_MAX[2]
_ULL_NEG_PEAK_AVG_MAX[0]
_ULL_NEG_PEAK_AVG_MAX[1]
_ULL_NEG_PEAK_AVG_MAX[2]
_ULL_POS_PEAK_AVG_MAX[0]
_ULL_POS_PEAK_AVG_MAX[1]
_ULL_POS_PEAK_AVG_MAX[2]
_ULL_PEAK_PEAK_AVG_MAX[0]
_ULL_PEAK_PEAK_AVG_MAX[1]
_ULL_PEAK_PEAK_AVG_MAX[2]
_U_STERN_AVG_MAX
_U_SYM_AVG_MAX
_FREQ_AVG_MAX
_NORM_FREQ_AVG_MAX
_PLN_AVG_MAX[0]
_PLN_AVG_MAX[1]
_PLN_AVG_MAX[2]
_PLN_AVG_MAX[3]
_P_SUM_AVG_MAX
_Q_SUM_AVG_MAX
_QLN_AVG_MAX[0]
_QLN_AVG_MAX[1]
_QLN_AVG_MAX[2]
_QLN_AVG_MAX[3]
_P_SUM3_AVG_MAX
_Q_SUM3_AVG_MAX
_ILN_AVG_MAX[0]
_ILN_AVG_MAX[1]
_ILN_AVG_MAX[2]
_ILN_AVG_MAX[3]
_SLN_AVG_MAX[0]
_SLN_AVG_MAX[1]
_SLN_AVG_MAX[2]
_SLN_AVG_MAX[3]
_I_SUM3_AVG_MAX
_I_SUM_AVG_MAX
_S_SUM3_AVG_MAX
_S_SUM_AVG_MAX
_THD_IL_AVG_MAX[0]
_THD_IL_AVG_MAX[1]
_THD_IL_AVG_MAX[2]
_THD_IL_AVG_MAX[3]
_ZHD_IL_AVG_MAX[0]
_ZHD_IL_AVG_MAX[1]
_ZHD_IL_AVG_MAX[2]
_ZHD_IL_AVG_MAX[3]
_ILN_CF_AVG_MAX[0]
_ILN_CF_AVG_MAX[1]
_ILN_CF_AVG_MAX[2]
_ILN_CF_AVG_MAX[3]
_IN_AVG_MAX
_IM_AVG_MAX
_IG_AVG_MAX
_I_SYM_AVG_MAX
_ILN_OVER_AVG_MAX[0]
_ILN_OVER_AVG_MAX[1]
_ILN_OVER_AVG_MAX[2]
Modbus-Adressenliste
Einheit Bemerkung
%
%
%
V
V
V
V
V
V
V
V
V
V
%
Hz
Hz
W
W
W
W
W
var
var
var
var
var
W
var
A
A
A
A
VA
VA
VA
VA
A
A
VA
VA
%
%
%
%
%
%
%
%
-
-
-
-
A
A
A
%
%
%
%
