Quick Start Guide
4
5
6
7
No. Name
1 Ventilation hole
2 Duplex module connector
3 Power cord connector
4 USB port
5 Serial RS232 port
6 Ethernet 10/100 Base-Tx port
7 Parallel port
1 2 3
Description
Releases heat to prevent the interior of the printer from heating up.
Connect the optional duplex module here.
Connect the power cord here.
Connect the USB cable here.
Connect the Serial cable here.
Connect the Ethernet cable here.
Connect the parallel cable here.
Chapter 1 Introduction
