Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work patterns.
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2.
1. Machine
2. Battery (not included)
3. Battery unlock button
4. Work light
5. On / off switch
6. Torque adjustment ring
7. Chuck
8. Gear selection switch
9. Direction switch
10. Belt hook
11. Operation mode ring
3. ASSEMBLY
Before any work on the power tool, remove
the battery.
The battery must be charged before first use.
Inserting the battery into the machine (Fig. B)
Ensure that the exterior of the battery is
clean and dry before connecting to the
charger or machine.
1. Insert the battery (2) into the base of the machine
as shown in Fig. B.
2. Push the battery further forward until it clicks
into place.
Removing the battery from the machine (Fig. B)
1. Push the battery unlock button (3)
2. Pull the battery out of the machine like shown
in Fig. B.
Fitting and removing drills or screwdriver bits (Fig. A)
The drill chuck (7) is suitable for drills and screw-
driver bits with round shaft as well as hexagonal
shaft.
1. Hold the machine firmly with one hand.
2. Open the drill chuck (7) by rotating the chuck
with your other hand in clockwise direction until
it is opened far enough for the bit to slide in.
3. Insert the shaft of the drill or screwdriver bit.
4. Tighten the drill chuck again by firmly rotating
6
the chuck (7) counterclockwise.
5. Check if the bit is centered well by shortly acti-
vating the machine´s on/off switch.

4. OPERATION

Adjusting the gears (Fig.A)
Never switch gears when the motor is
running, this will damage your machine.
Never put switch in the middle between both
positions, this will damage your machine.
The machine has 2 drill speeds, which can be
adjusted by sliding the gear switch (8) forward
or backwards. The number on the gear switch (8)
shows which position is chosen.
• Position 1: For slow drilling, large drilling dia-
meter or screw driving. The machine has high
power at a low speed.
• Position 2: For fast drilling or small drilling
diameter.
Adjusting the direction of rotation (Fig. A)
• Set the direction switch (9) to position
order to drive screws or to use it for drilling.
• Set the direction switch (9) to position
order to remove screws.
Switching the machine on and off (Fig. A)
The on/off switch (5) is used for activating the
machine and adjusting rotation speed.
• Pressing the on/off switch (5) will activate the
machine, the further the switch is being pus-
hed, the faster the drill will turn.
• Releasing the on/off switch (5) will stop the
machine.
• Move the direction reversing switch (9) to the
middle position to lock the movement of the on/
off switch.
Setting the operating mode (Fig. A)
Screwdriving
• Set the operation mode ring (11) to the "screw-
driving" symbol and set the torque adjustment
ring (6) to the required torque.
• By rotating the torque adjustment ring (6),
screws can be driven to a predetermined depth,
which is ideal for repetitive work. The higher the
number, the more torque will be transmitted.
• Select a low setting for small screws or soft
in
in
