1
Description
3
4
5
6
7 8
20
21
22
18 GB
Downloaded from www.Manualslib.com
1 2
Sender TX
1
2
3
4
5
6
9 10
7
8
9
10 Optional: Test clamp, black -
11 Connecting cable, red +
11
12 Connecting cable, black -
12
13
14
15
16
17
18
19
23
manuals search engine
Connecting socket, red +
Connecting socket, black -
LC display
Sender code button:
Settings output power trans-
mission signal / illumination
LC display (hold button
down for 2 seconds) / set
sender code
ON/OFF buttonOFF: hold
button down for 2 seconds
Battery compartment (rear)
Test prod, red +
Test prod, black -
Optional: Test clamp, red +
Receiver RECV
13 Sensor head
14 Flashlight
15 LC display
16 Toggle measurement mode: Locate cables (SIG) / Locate
mains voltage (NCV)
17 ON/OFF button flash light
18 Reduce sensitivity
19 Toggle manual / automatic search mode
20 Illumination LC display /Turn on/off acoustic signal
(hold button down for 2 seconds)
21 Increase sensitivity
22 ON/OFF button - OFF: hold button down for 2 seconds
23 Battery compartment (rear)
C B
A
LC display sender TX
A Sender code (1,2,3,4,5,6,7)
B External voltage warning
C Display external voltage
(12, 50, 120, 230, 400V)
D Low battery charge
E Display output power
transmission signal
(level I, II, III)
D
E
