Returning to saved positions

Press the appropriate M1, M2 or M3 button and keep it depressed until
the desired position has been reached and the drives switch off.
Warning and error messages for eLevel /
eLevel+
Warnings and error messages can be shown at the manual switch
display.
These messages are generated by the control system and supply
information about malfunctions and their causes.
Code Cause
E 106 Short circuit at the
manual switch port
E 212 Short circuit at the
Hall sensor
F 215 Short circuit at the
motor port
F 222 EEPROM read/write
error
F 233 MOSFET defective
A 0 SC reset OK
A 99 Overrun display
A 100 Enforced reset
manuals search engine
Troubleshooting
The control system has detected a short
circuit at the manual switch port.
Operation of the control system will be
blocked for approx. 10 seconds. Rectify the
fault. After this the control system must be
reinitialised.
The control system has detected a short
circuit at the Hall sensor or at one or more
drives. Operation of the control system will
be blocked for approx. 10 seconds. Rectify the
fault. After this the control system must be
reinitialised.
The control system has detected a short
circuit at the power supply or at one or more
drives. Operation of the control system will
be blocked for approx. 10 seconds. Rectify the
fault. After this the control system must be
reinitialised.
System overload! Disconnect the device from
the mains. If the same error message is still
reported after 10 hours, contact your custom-
er service.
The control system must be reinitialised.
